SV叉形孔冷压线鼻型号参数：
导线截面0.5~1.5mm²（A.W.G22~16）最大电流1max=19A 材质：紫铜
|
型号
|
美制螺栓号
|
螺栓口径d2（mm）
|
尺寸
|
颜色
|
|
B
|
L
|
F
|
H
|
Dφ
|
|
SV 1.25-3
|
＃4
|
3.2
|
5.7
|
21.2
|
6.5
|
10.0
|
4.3
|
红
|
|
SV 12.5-3.5S
|
＃5
|
3.7
|
5.7
|
21.2
|
6.5
|
|
SV 12.5-3.5L
|
＃5
|
3.7
|
6.4
|
21.2
|
6.5
|
|
SV 12.5-4S
|
＃8
|
4.3
|
6.4
|
21.2
|
6.5
|
|
SV 12.5-4M
|
＃8
|
4.3
|
7.2
|
21.2
|
6.5
|
|
SV 12.5-4L
|
＃8
|
4.3
|
8.1
|
21.2
|
6.5
|
|
SV 12.5-5S
|
＃10
|
5.3
|
8.1
|
21.2
|
6.5
|
|
SV 12.5-5L
|
＃10
|
5.3
|
9.5
|
21.2
|
6.5
|
|
SV 12.5-6S
|
1/4
|
6.5
|
9.5
|
21.2
|
6.5
|
|
SV 12.5-6L
|
1/4
|
6.5
|
12.0
|
27.2
|
11.0
|
|
SV 12.5-8
|
5/16
|
8.5
|
14.0
|
29.0
|
12.5
|
导线截面1.5~2.5mm²（A.W.G16-14）最大电流1max=27A 材质：紫铜
|
型号
|
美制螺栓号
|
螺栓口径d2（mm）
|
尺寸
|
颜色
|
|
B
|
L
|
F
|
H
|
Dφ
|
|
SV2-3
|
＃4
|
3.2
|
5.7
|
21.2
|
6.5
|
10.0
|
4.9
|
蓝
|
|
SV2-3.5S
|
＃6
|
3.7
|
5.7
|
21.2
|
6.5
|
|
SV2-3.5L
|
＃6
|
3.7
|
6.4
|
21.2
|
6.5
|
|
SV2-4S
|
＃8
|
4.3
|
6.4
|
21.2
|
6.5
|
|
SV2-4M
|
＃8
|
4.3
|
7.2
|
21.2
|
6.5
|
|
SV2-4L
|
＃8
|
4.3
|
8.1
|
21.2
|
6.5
|
|
SV2-5S
|
＃10
|
5.3
|
8.1
|
21.2
|
6.5
|
|
SV2-5L
|
＃10
|
5.3
|
9.5
|
21.2
|
6.5
|
|
SV2-6S
|
1/4
|
6.5
|
9.5
|
21.2
|
6.5
|
|
SV2-6L
|
1/4
|
6.5
|
12.0
|
27.2
|
11.0
|
|
SV2-8
|
5/16
|
8.5
|
14.0
|
29.0
|
12.5
|
导线截面2.5~4mm²（A.W.G14-12）最大电流1max=37A 材质：紫铜
|
型号
|
美制螺栓号
|
螺栓口径d2（mm）
|
尺寸
|
颜色
|
|
B
|
L
|
F
|
H
|
Dφ
|
|
SV3.5-3
|
＃4
|
3.2
|
5.7
|
24.8
|
7.0
|
12.5
|
6.2
|
黑
|
|
SV3.5-4
|
＃8
|
4.3
|
8.0
|
24.8
|
7.0
|
|
SV3.5-5
|
＃10
|
5.3
|
8.0
|
248
|
7.0
|
|
SV3.5-6
|
1/4
|
6.4
|
12.0
|
28.0
|
12.1
|
导线截面4~6mm²（A.W.G12-10）最大电流1max=48A 材质：紫铜
|
型号
|
美制螺栓号
|
螺栓口径d2（mm）
|
尺寸
|
颜色
|
|
B
|
L
|
F
|
H
|
Dφ
|
|
SV5.5-3.5
|
＃6
|
3.7
|
8.3
|
25.2
|
7.5
|
12.5
|
6.7
|
黄
|
|
SV5.5-4S
|
＃8
|
4.3
|
8.3
|
25.2
|
7.5
|
|
SV5.5-4L
|
＃8
|
4.3
|
9.0
|
25.2
|
7.5
|
|
SV5.5-5
|
＃10
|
5.3
|
9.0
|
25.2
|
7.5
|
|
SV5.5-6S
|
1/4
|
6.5
|
9.0
|
25.2
|
7.5
|
|
SV5.5-6L
|
1/4
|
6.5
|
12.0
|
31.2
|
12.0
|
|
SV5.5-8
|
5/16
|
8.4
|
14.0
|
30.0
|
11.5
|
